Keypoint Summary

• Pallet shuttle racking uses a remote controlled, motorised shuttle to move pallets automatically within deep storage lanes, removing the need for forklifts to enter the structure.
• It combines high storage density with faster loading and unloading than drive in racking, since the shuttle handles internal movement rather than the forklift.
• The system supports both last in first out and first in first out configurations, depending on how the lanes are set up.
• It suits businesses storing large volumes of a limited number of SKUs, particularly in cold storage, food and beverage, and high throughput distribution.
• Krost Shelving & Racking is one of South Africa and Africa’s leading manufacturers of pallet shuttle racking, designing every system around your actual stock and throughput needs.

Search interest in semi-automated storage systems has been climbing steadily as South African warehouses look for ways to increase density and throughput without expanding their footprint, and pallet shuttle racking sits right at the centre of that shift. It is still a relatively unfamiliar system to many businesses, despite offering real advantages over more traditional high density options like drive in racking. This guide explains how pallet shuttle racking actually works, what sets it apart, and the kind of operation that benefits most from it.

What Is Pallet Shuttle Racking?

Pallet shuttle racking is a semi-automated, high density storage system that uses a remote controlled shuttle to move pallets within deep storage lanes, rather than relying on a forklift to drive into the structure itself. The racking is built with continuous rails, similar in principle to drive in racking, but instead of a forklift entering the lane to place each pallet, the forklift loads a pallet at the entrance and the shuttle carries it into position automatically.

This shift, from forklift driven placement to shuttle driven placement, is what separates pallet shuttle racking from drive in racking, and it changes the economics of high density storage considerably. Because the forklift never enters the lane itself, loading and unloading is faster, safer, and causes far less wear on the racking structure than repeated forklift entries.

How Pallet Shuttle Racking Works

A pallet shuttle system consists of the racking structure itself, built with rails along each storage lane, and a battery powered shuttle unit that sits within the lane. A forklift places a pallet at the entrance of the lane and loads it onto the shuttle, which is then controlled remotely, typically from a handheld device, to carry the pallet along the rails and set it down in the correct position.

The shuttle can be configured to work on a last in first out basis, similar to drive in racking, or set up for first in first out operation, similar to drive thru racking, depending on how the lane and shuttle are configured. Some systems use a single shuttle moved between lanes as needed, while higher throughput operations may use multiple shuttles working simultaneously across different lanes.

Because the shuttle handles all movement within the lane, the forklift’s job is reduced to loading and unloading at the entrance, which significantly cuts the time and distance a forklift needs to travel compared to a drive in system where it must enter and reverse out of the lane for every single pallet.

Key Benefits of Pallet Shuttle Racking

Faster loading and unloading. Since the shuttle handles internal movement, forklifts spend far less time per pallet than they would entering and exiting a drive in lane manually.

High storage density. Like drive in racking, pallet shuttle systems store pallets several deep within a single lane, making efficient use of floor space for bulk storage.

Reduced racking and product damage. Because forklifts no longer enter the lane itself, the collision damage that can occur with drive in racking is significantly reduced, both to the structure and to the stock.

Flexible rotation options. Depending on configuration, the system can support either last in first out or first in first out handling, giving more flexibility than drive in racking alone.

Improved safety. Removing the need for forklifts to manoeuvre deep within a racking structure reduces a meaningful source of warehouse accidents.

Lower long term operating cost for high volume storage. While the upfront investment is higher than drive in racking, the reduced forklift time and lower damage rates can offset that cost for operations with sufficiently high throughput.

Who Needs Pallet Shuttle Racking?

Pallet shuttle racking tends to make the most sense for businesses with a specific combination of needs: large volumes of a limited number of SKUs, high throughput requirements, and a genuine need to reduce forklift handling time or damage rates.

Cold storage and food and beverage. These industries frequently combine high volume, limited SKU storage with strict rotation requirements, making pallet shuttle racking, particularly in a first in first out configuration, a strong fit.

High throughput distribution centres. Operations moving large quantities of stock quickly benefit from the reduced forklift time per pallet, which can meaningfully improve overall throughput.

Businesses outgrowing drive in racking. Companies already using drive in racking but experiencing high forklift wear, racking damage, or bottlenecks at peak periods are natural candidates for upgrading to a shuttle system.

Operations with limited labour availability. Because the shuttle reduces the manual forklift work involved in deep lane storage, it can help operations manage throughput with fewer forklift hours.

It is worth being realistic about where pallet shuttle racking does not make sense. Businesses with a wide range of SKUs needing individual pallet access are generally better served by selective pallet racking, and operations without sufficiently high volume in a single lane may not see enough benefit to justify the additional investment over drive in racking.

Choosing the Right Pallet Shuttle System

Getting a pallet shuttle system right depends on matching lane depth, shuttle capacity, and rotation configuration to your actual stock profile and throughput. Specifying too few shuttles for your volume can create bottlenecks, while over specifying adds unnecessary cost. This is exactly the kind of decision that benefits from proper site assessment rather than a generic package.

Krost Shelving & Racking is one of South Africa and Africa’s leading manufacturers of pallet shuttle racking, designing every system around your actual stock, throughput, and rotation requirements rather than fitting your operation to an off the shelf configuration.

Frequently Asked Questions

How is pallet shuttle racking different from drive in racking?

Drive in racking requires a forklift to enter the lane to place and retrieve every pallet. Pallet shuttle racking uses a remote controlled shuttle to move pallets within the lane instead, so the forklift only loads and unloads at the entrance.

Does pallet shuttle racking support first in first out rotation?

Yes, depending on configuration. The system can be set up for either last in first out or first in first out handling, making it more flexible than drive in racking alone.

Is pallet shuttle racking more expensive than drive in racking?

Generally yes, due to the shuttle equipment and battery systems involved, though the reduced forklift time and lower damage rates can offset that cost for high throughput operations over time.

How many pallets can a single shuttle handle?

This depends on the specific shuttle model and lane configuration. Higher throughput operations may use multiple shuttles across different lanes rather than relying on a single unit.

Is pallet shuttle racking suitable for cold storage?

Yes, it is a common choice for cold storage environments, since it combines high density storage with reduced forklift time inside the cold zone, which also has energy and staff comfort benefits.

Does Krost supply and install pallet shuttle racking?

Yes. Krost Shelving & Racking designs, manufactures, and installs pallet shuttle racking systems in house, tailored to your specific stock, throughput, and rotation requirements.

Final Thoughts

Pallet shuttle racking represents a genuine step up from drive in racking for businesses with the volume and throughput to justify it, offering higher density, faster handling, and reduced damage in one system. As awareness of semi-automated storage grows across South African warehousing, it is increasingly worth a closer look for any operation storing large volumes of a limited product range.

For a full breakdown of every racking type and how to choose between them, see our complete guide to racking systems. You can also view our Pallet Shuttle Racking range directly, or get in touch with our team for a free site assessment to see whether a shuttle system fits your operation
